HC62109F-B

Model:WSD-A09 Fuel Type :Hard wood Material :CRS,HRS Finish :Forest paint ,NEG glass Nominal Output:8.5KW Product size(mm) :706*554*819 Package size (mm):790*620*930 Net weight :100KG Gross weight :120KG Loading quantity (40GP):105 Other：Cast iron door，cast iron legs,big ash drawer

Model:WSD-A09 Fuel Type :Hard wood Material :CRS,HRS Finish :Forest paint ,NEG glass Nominal Output:8.5KW Product size(mm) :706*554*819 Package size (mm):790*620*930 Net weight :100KG Gross weight :120KG Loading quantity (40GP):105 Other：Cast iron door，cast iron legs,big ash drawer

Item Code: WSD-CN3-1 Material : Cold rolled steel, Forrest metallic black paint + NEG ceramic glass Nominal Output: 6 KW, 8KW Approval: CE, DIN EN13240 Efficiency: 80% Emissions: 1000mg/Nm³ Product Size: W610*D443*H1343mm Gross Weight: 282kgs Loading in 40GP: 63pcs

Item Code: WSD-BM5 Material : Cold rolled steel, Forrest metallic black paint + NEG ceramic glass Nominal Output: 6 KW, 8KW Approval: CE, DIN EN13240 Efficiency: 81% Emissions: 875mg/Nm³ Product Size: W530*D470*H1145mm Gross Weight: 171kgs Loading in 40HQ: 144pcs

Item Code: WSD-F02 Fuel type: Wood Material of stove body: Cold rolled steel Finish:High temperature paint,black Nominal output:7KW Product Size: W556*D475*H908mm Package Size: W650*D580*H1030mm Net Weight: 90kgs Gross Weight: 108kgs Qty in container(40GP): 120pcs Other: log storage and coffee table

Item Code: WSD-D02 Fuel Type :wood Material of stove body: Cold rolled steel Finish :High temperature paint,black Approval:CE Nominal output:8.5KW Efficiency:75.1% Product size(mm) :562(W)*472(D)*829(H) Package size (mm): 615(W)*525(D)*968(H) Net weight :110KG Gross weight :128KG Qty in container(40GP):160

Brand Name: Lundberg Model Info: HB5202C-S/HB5102C-S Width(cm): 50 Voltage/Frequency: 220-240V/50HZ Number of motors and power: 120W / 240W Type of speed control: rocker switch Extraction rate.(ducting)m3/h: 350/450 Noise Level (db): ≤55/≤57 Grease Filter: Alu.2x3 layers Packing Dimensions(W×D×H): 550×380×355 Gross Weight(kg): 10 Net Weight(kg): 9 Container Loading Qty.(20’/40’/40HQ) : 384/768/896

Brand Name: Lundberg Model Info: HC6213A-S(SS)/HC9213A-S(SS) Width(cm): 60/90 Voltage/Frequency: 220-240V/50HZ Number of motors and power: 100W/200W Type of speed control: Push button Extraction rate.(ducting)m3/h: 650/850 Noise Level (db): ≤55/≤57 Grease Filter: Alu.2x4layers Packing Dimensions(W×D×H): 650X330X555 Gross Weight(kg): 19.5 Net Weight(kg): 17.5 Container Loading Qty.(20’/40’/40HQ) : 252/500/500

Brand Name: Lundberg Model Info: HC9208A-W Width(cm): 90 Voltage/Frequency: 220-240V/50HZ Number of motors and power: 100W/200W Type of speed control: Push button Extraction rate.(ducting)m3/h: 650/850 Noise Level (db): ≤55/≤57 Grease Filter: Alu.2x4layers Packing Dimensions(W×D×H): 950X420X555 Gross Weight(kg): 23 Net Weight(kg): 20 Container Loading Qty.(20’/40’/40HQ) : 136/272/272

Brand Name: Lundberg Model Info: HF6101A-WB/ HF6201A-WB Width(cm): 60 Voltage/Frequency: 220-240V/50HZ Number of motors and power: 1X120W/2X120W Type of speed control: Push button Extraction rate.(ducting)m3/h: 300/450 Noise Level (db): ≤58 Grease Filter: acrylic Packing Dimensions(W×D×H): 630X175X540 Gross Weight(kg): 8/10 Net Weight(kg): 7/9 Container Loading Qty.(20’/40’/40HQ) : 456/940/1056
